The current page: Home - Polyphenylene Sulfide (PPS)Polyphenylene Sulfide (PPS)
Filled PPS ( PPS+GF+Min+Ca....)
Filled PPS ( PPS+GF+Min+Ca....)
Filled PPS ( PPS+GF+Min+Ca....)
CAS No.: 26125-40-6
Appearance: White/brown pallets
Specification:
| Item | Test Standard | Unit | Closs-linked | Linear | Modified elastomer | |||
| CF-G3 | CF-G4 | CF-M7 | CF-LG4 | CF-LM6 | G3B3 | |||
| Filler(contend,%) | GF,30% | GF,40% | GF+Mineral,65% | GF,40% | GF+Mineral,60% | GF,30% | ||
| Density | ISO 1183 | g/cm3 | 1.56 | 1.66 | 1.95 | 1.66 | 1.9 | 1.52 |
| Water Absorption | ISO62 | wt% | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 | 0.02 |
| Mold Shrinkage, MD/TD | ISO294-4 | % | 0.25/0.75 | 0.25/0.65 | 0.25/0.55 | 0.25/0.65 | 0.25/0.60 | 0.30/0.85 |
| Tensile Strength | ISO527-1,2 | MPa | 160 | 180 | 165 | 190 | 170 | 140 |
| Break Elongation | ISO527-1,2 | % | 1.9 | 1.8 | 1.1 | 1.8 | 1.2 | 2.3 |
| Flexural Strength | ISO178 | MPa | 240 | 270 | 240 | 280 | 250 | 225 |
| Flexural Modulus | ISO178 | GPa | 10 | 13 | 19 | 13 | 17 | 9 |
| Izod Impact Strength (notched) | ISO 180A | KJ/M | 10 | 11 | 8 | 12 | 9 | 15 |
| Melting Point | ISO 75-2 | R/M scale | 282 | 285 | 285 | 280 | 280 | 275 |
| HDT (1.8MPa) | ISO 3146 | ℃ | 265 | 265 | 265 | 265 | 265 | 260 |
| Volume Resistivity | IEC 60093 | Ω ∙ m | 1014 | 1014 | 1014 | 1014 | 1014 | 1014 |
| Dielectric Strength | ISO 60243-1 | KV/mm | 15 | 15 | 15 | 16 | 16 | 15 |
| Dielectric Constant | IEC60250 | 1MHz | 4.2 | 4.2 | 4.5 | 4 | 4.5 | 4.5 |
| Dissipation Factor | IEC60250 | 1MHz | 0.002 | 0.002 | 0.005 | 0.002 | 0.005 | 0.005 |
| Comperative tracking index(CTI) | IEC 60112 | V | 175 | 175 | 200 | 175 | 200 | 175 |
| Flammability (Vertical) | UL94 | V-0 | V-0 | V-0 | V-0 | V-0 | V-0 | |
