E1L Series
E1L Series
E1L Series

Features: Excellent Processing Properties, Fast Setting Time, No Migration, UV Resistance, Excellent Flowability.

Applications: Phone&Pad Cover, Conveyor Belt, Hose&Tube, Wire&Cable, Footwear, Caster, Film, Coating, Overmolding, etc.

Properties Standard Unit E185L E190L E195L
Density ASTM D792 g/cm3 1.19 1.19 1.2
Hardness ASTM D2240 A/D 86/- 92/- 95/-
Tensile Strength ASTM D412 MPa 25 40 45
100% Modulus ASTM D412 MPa 5 10 15
300% Modulus ASTM D412 MPa 10 20 25
Elongation at Break ASTM D412 600 550 500
Tear Strength ASTM D624 kN/m 100 120 130
Tg DSC °C -35 -25 -20

NOTE: The above values are shown as typical values and should not be used as specifications.
